Bemis Case Erector Bag Inserter 1575
Back to All EquipmentBemis Model 1575, automatic, poly bag inserter rated from 5 to 15 bags per minute – depending on materials and application. Case size range: 8" to 20" in Length; 4" to 16" in Width; 10" to 22" in Height (with top flap in vertical position). Bag size relative to case: length, width, depth +5" to +7". Equipped with bag vacuum pick and place, bag opener, single ram bag inserter and cuffer with self contained vacuum pump. Control panel has A/B CPU controller with machine and bag feed on / off switches, start / e-stop push button controls and mounted on height adjustable base frame with Lexan safety guarding and status light bar. Bag Roll Specifications: up to 14" in Diameter; up to 27-1/2" in Width; with 1-1/2" OD core.
OAD: 82" L x 54" W x 103" H
