Back to All EquipmentFalco Stainless Steel Equipment Co, 200 gallon, stainless steel jacketed process reactor tank. 316L exterior with # 7 finish and 316L electro polished finish. Vessel dimensions: 55" OD x 66" deep with 36" straight wall and 26" slant bottom. Equipped with dome top and has 16" OD manway with flip up, bolt down cover, top mounted 5 Hp motor drive for scrape surface and prop agitators with full side and bottom 3 zone jacket. Slant bottom with 3" OD flush bottom center bottom discharge valve with 16" ground clearance. Mounted on stainless steel (3) leg frame.
Top Ports:
(2) 1-1/2"
(2) 2"
Jacket Ports:
(6) 1-1/2"
Vessel:
MAWP: 100 psi @ 300°F
MDMT: -32 °F @ 100 psi
Jacket:
MAWP: 150 psi @ 300°F
MDMT: 32°F @ 150 psi
OAD: 55" L x 53" W x 87" H
