幸福Mill Hammer E1906

Photo of Bliss Mill Hammer E1906
Thumbnail of Bliss Mill Hammer E1906 Thumbnail of Bliss Mill Hammer E1906 Thumbnail of Bliss Mill Hammer E1906 Thumbnail of Bliss Mill Hammer E1906 Thumbnail of Bliss Mill Hammer E1906 Thumbnail of Bliss Mill Hammer E1906 Thumbnail of Bliss Mill Hammer E1906 Thumbnail of Bliss Mill Hammer E1906 Thumbnail of Bliss Mill Hammer E1906

幸福Mill Hammer E1906

  • Manufacturer:幸福
  • Model Number:E1906
  • Frain Number:5E9992

Heavy duty, mild steel, dual screen, hammer mill, with 576 sq inch screen area and up to 1740 rpm, production rates – depending on materials and application. Equipped with a 13" x 9-1/2" OD, 9" x 6" ID top flanged product in feed with (8) 3/8" bolt holes on 5-1/2" centers, octagonal housing, 9" OD recessed reversible rotor with (8) 6" Long x 2" Wide knife / blunt swing blades. Side access doors with one piece, spring loaded, quick change screen carriage, drive shaft locking device, adjustable non leak air sweep, saftey and vibration sensor switches, 10" x 7-1/2" OD, 7" x 4-1/2" ID side bottom flanged discharge port with (6) 3/8" bolt holes on 4" centers, and 9" x 7" OD air relief port, 10 hp drive, and a start/stop control package. Mounted on heavy duty base frame.

OAD: 48" L x 29" W x 44" H

Get a Free Quote Call:630-629-9900

幸福Mill Hammer E1906

Photo of Bliss Mill Hammer E1906
Thumbnail of Bliss Mill Hammer E1906 Thumbnail of Bliss Mill Hammer E1906 Thumbnail of Bliss Mill Hammer E1906 Thumbnail of Bliss Mill Hammer E1906 Thumbnail of Bliss Mill Hammer E1906 Thumbnail of Bliss Mill Hammer E1906 Thumbnail of Bliss Mill Hammer E1906 Thumbnail of Bliss Mill Hammer E1906 Thumbnail of Bliss Mill Hammer E1906

幸福Mill Hammer E1906

  • Manufacturer:幸福
  • Model Number:E1906
  • Frain Number:5E9990

幸福Model E1906, Heavy duty, mild steel, dual screen, hammer mill, with 576 square inch screen area and up to 1740 rpm production rates – depending on materials and application. Equipped with a 13" x 9-1/2" OD, 9" x 6" ID top flanged product in feed with (8) 3/8" bolt holes on 5-1/2" centers, octagonal housing, 9" OD recessed reversible rotor with (8) 6" Long x 2" Wide knife / blunt swing blades. Side access doors with one piece, spring loaded, quick change screen carriage, drive shaft locking device, adjustable non leak air sweep, saftey and vibration sensor switches, 10" x 7-1/2" OD, 7" x 4-1/2" ID side bottom flanged discharge port with (6) 3/8" bolt holes on 4" centers, and 9" x 7" OD air relief port, 10 hp drive, and a start/stop control package. Mounted on heavy duty base frame.

OAD: 48" L x 29" W x 44" H
